型号 |
Model |
VSLA530x1500/2000 |
VSLA600x1500/2000 |
VSLA680x1500/2000 |
|
产品编号 |
Code No. |
P4253400/P4253500 |
P4260400/P4260500 |
P4268400/P4268500 |
|
加工范围 |
Capacity |
|
|
|
|
床身上*大回转直径 |
Swing over bed |
Φ530mm |
Φ600mm |
Φ680mm |
|
拖板上*大回转直径 |
Swing over cross slide |
Φ329mm |
Φ399mm |
Φ479mm |
|
马鞍上*大回转直径 |
Swing in GAP(D×W) |
Φ765×218mm(D1-8)
/Φ765×240mm(A1-8) |
Φ838mm×218mm(D1-8)
/Φ835×240mm(A1-8) |
Φ918mm×218mm(D1-8)
/Φ915×240mm(A1-8) |
|
主轴中心高 |
Height of center |
265mm |
300mm |
380mm |
|
两顶尖中心距 |
Distance between centers |
1500/2000mm |
1500/2000mm |
1500/2000mm |
|
床身宽度 |
Width of bed |
400mm |
400mm |
400mm |
|
主轴 |
Headstock |
|
|
|
|
主轴通孔直径 |
Spindle bore |
Φ82 |
Φ82 |
Φ82 |
|
主轴端部 |
Spindle nose |
D1-8 or A1-8 |
D1-8 or A1-8 |
D1-8 or A1-8 |
|
主轴内外锥度 |
Spindle morse taper in nose,in sieeve |
ME90/MT5 |
ME90/MT5 |
ME90/MT5 |
|
主轴转速级数 |
Spindle speeds number |
12 |
12 |
12 |
|
主轴转速范围 |
Spindle speeds range |
20-1600rpm |
20-1600rpm |
20-1600rpm |
|
进给及螺纹 |
Feeds and threads |
|
|
|
|
车刀杆*大尺寸 |
Cutting tool max.section |
25x25mm |
30x30mm |
25x25mm |
|
中拖板总行程 |
Total travel of cross slide |
320mm |
358mm |
438mm |
|
小拖板总行程 |
Total travel of top slide |
200mm |
200mm |
200mm |
|
英制螺纹范围 |
Threads imperial pitches |
4-112TPI |
4-112TPI |
4-112TPI |
|
公制螺纹范围 |
Threads metric pitches |
0.25-7mm |
0.25-7mm |
0.25-7mm |
|
尾架 |
Tailstock |
|
|
|
|
尾座套筒行程 |
Total travel of tailstock quill |
180mm |
180mm |
180mm |
|
尾座套筒直径 |
Tails stock quill |
Φ80 |
Φ75 |
Φ80 |
|
尾座套筒内孔锥度 |
Taper tailstock quill |
MT5 |
MT5 |
MT5 |
|
电机 |
Motor |
|
|
|
|
主轴电机 |
Spindle drive motor |
7.5KW |
7.5KW |
7.5KW |
|
冷却泵电机功率 |
Coolant pump motor |
0.09KW |
0.09KW |
0.09KW |
|
外形尺寸及重量 |
Dimension and weight |
|
|
|
|
净重 |
Net weight |
2750/3010kg |
2820/3080kg |
2900/3160kg |
|
毛重 |
Cross weight |
3090/3400kg |
3180/3490kg |
3260/3570kg |
|
包装尺寸 |
Packing size |
3335x1110x1900mm |
3335x1110x1900mm |
3270/3770x1150x1900mm |
