型号 |
MODEL |
VSSK6128 |
VSSK6148 |
VSSK6168 |
VSSK6198 |
VSSK6208 |
|
产品编号 |
Code No. |
C1312200 |
C1314200 |
C1316200 |
C1319200 |
C1320200 |
|
床身上*大回转直径 |
Max swing over bed |
Ø1280mm |
Ø1480mm |
Ø1680mm |
Ø1980mm |
Ø2080mm |
|
横拖板*大回转直径 |
Max swing over cross slide |
Ø840mm |
Ø1040mm |
Ø1240mm |
Ø1540mm |
Ø1640mm |
|
顶尖距 |
Center distance |
2-16M |
2-16M |
2-16M |
2-16M |
2-16M |
|
主轴孔径 |
Spindle hole |
Ø130mm |
Ø130mm |
Ø130mm |
Ø130mm |
Ø130mm |
|
床身宽度 |
Bed width |
1100mm |
1100mm |
1100mm |
1100mm |
1100mm |
|
尾座套筒直径 |
Diameter of tailstock sleeve |
Ø260mm |
|
刀架位移*大距离 |
Max distance of moving tool-post |
|
|
|
|
|
纵向 |
Longitude |
两顶尖距 Admits between -600mm |
|
横向 |
Transverse |
800mm |
800mm |
800mm |
800mm |
800mm |
|
主轴转速范围（级数） |
Spindle speeds(Number) |
3.15-315r/min or 2.5-250(21)r/min or 2-200r/min 5-20 15-60 25-100 65-250 |
|
主电机功率 |
Main motor power |
30kw |
|
快速移动速度 |
Speed of high-speed movement |
|
|
|
|
|
纵向 |
Longitude |
4000mm/min |
|
横向 |
Transverse |
3000mm/min |
|
刀架装刀数（自动换刀） |
Tool numbers on tool-post |
4（6、8 可选 optional） |
|
定位精度 |
Positioning accuracy |
|
|
|
|
|
|
纵向 |
Longitude |
0.05mm |
0.05mm |
0.05mm |
0.05mm |
0.05mm |
|
横向 |
Transverse |
0.03mm |
0.03mm |
0.03mm |
0.03mm |
0.03mm |
|
机床重复定位精度 |
Repeatability |
|
|
|
|
|
|
纵向 |
Longitude |
±0.025mm |
±0.025mm |
±0.025mm |
±0.025mm |
±0.025mm |
|
横向 |
Transverse |
±0.012mm |
±0.012mm |
±0.012mm |
±0.012mm |
±0.012mm |
|
刀架重复定位精度 |
Repeatability accuracy of tool-post |
±0.005mm |
±0.005mm |
±0.005mm |
±0.005mm |
±0.005mm |
|
净重（KG） |
NET WEIGHT |
|
|
|
|
|
|
SK61168*4000mm |
SK61168*4000mm |
22000kg |
22000kg |
22000kg |
22000kg |
22000kg |
|
外形尺寸（长*宽*高） |
FLOOR SPACE(L*W*H) |
|
|
|
|
|
|
SK61168*4000mm |
SK61168*4000mm |
7300*3000*2500 |
