数控系统：西门子系统、法那克系统、华中系统、广数系统等国产或进口系统可根据用户选配。
|
型号 |
Type |
VSS400PS CNC |
VSS600PS CNC |
|
产品编号 |
Code No. |
C1540100 |
C1560100 |
|
床身上*大回转直径 |
Swing over bed |
ø450mm |
ø500mm |
|
拖板上*大回转直径 |
swing over cross slide |
ø220mm |
ø250mm |
|
行程 |
Travel |
|
|
|
X轴 |
X axis |
230mm |
250mm |
|
Z轴 |
Z axis |
530mm |
850mm |
|
主轴 |
Spindle |
|
|
|
主轴通孔直径 |
Spindle hole diameter |
ø51mm（可选optional ø79mm) |
ø61mm |
|
主轴转速 |
Spindle speed |
4500rpm (ø79mm 3000rpm) |
4000rpm |
|
电机功率 |
Motor Power |
7.5KW (可选optional 12/15KW) |
12KW |
|
轴向进给率 |
Axes feed rate |
|
|
|
X轴快速进给率 |
X axis Rapid feed |
12m/min |
24m/min |
|
Z轴快速进给率 |
Z axis Rapid feed |
10m/min |
24m/min |
|
精度 |
Accuracy |
|
|
|
定位精度 |
Positioning accuracy |
±0.025mm |
±0.025mm |
|
重复精度 |
Repeatability accuracy |
±0.01mm |
±0.01mm |
|
切削能力 |
Capacity |
|
|
|
刀具*大截面 |
Max. section of tool |
25x25mm |
25x25 mm |
|
*大切削直径 |
Max. turning diameter(with turret) |
ø400mm |
ø400mm |
|
*大切削长度 |
Max. turning length(with turret) |
430mm |
750mm |
|
床身斜度（角度） |
Slant bed degree |
45° |
45° |
|
尾座 |
Tailstock |
|
|
|
套筒行程 |
Quill travel |
100mm |
100mm |
|
套筒直径 |
Quill diameter |
ø72mm |
ø72mm |
|
套筒锥度 |
Quill inside taper |
MT4 |
MT4 |
|
冷却 |
Coolant |
|
|
|
电机 |
Pump motor |
650W |
450W |
|
水箱容量 |
Tank capacity |
200L |
100L |
|
外形尺寸及重量 |
Dimensions and weight |
|
|
|
外形尺寸 |
Dimension |
3650x1410x1760mm |
3850x1850x1920mm |
|
包装尺寸 |
Packing size |
2816x2240x1998mm |
/ |
|
净重/毛重 |
Net weight/Gross weight |
3600/4100kg |
3800/4300 kg |
