型号 |
Model |
VSLC 400x1000 |
|
产品编号 |
Code No. |
PX4240300 |
|
两顶尖中心距 |
Distance between centers |
1000mm |
|
主轴中心高 |
Center height |
200mm |
|
床身上*大回转直径 |
Swing over bed |
ø400mm |
|
马鞍上*大回转直径 |
Swing over gap |
ø506mm |
|
拖板上*大工件回转直径 |
Swing over cross slide |
ø240mm |
|
床身宽度 |
Bed width |
210mm |
|
主轴通孔直径 |
Spindle bore |
ø52mm |
|
主轴端部 |
Spindle nose fixture |
DIN55029,D1-5 |
|
主轴转速 |
Speed range |
(12)45-2000rpm |
|
公制螺纹范围 |
Metric thread |
(36)0.8-14mm |
|
英制螺纹范围 |
Inch thread |
(30)2-28TPI |
|
尾座套筒直径 |
Diameter of tailstock sleeve |
ø45mm |
|
尾座套筒行程 |
Travel of tailstock sleeve |
100mm |
|
尾座套筒锥度 |
Taper of tailstock sleeve |
MT4 |
|
电机功率 |
Motor power |
2.4kw/2.0kw |
|
包装尺寸 |
Packing size |
1930x760x1540mm |
|
净重/毛重 |
N.W./G.W. |
820/860kg |
