型号 |
Type |
VSLT50 |
VSLT50V |
|
货号 |
Item No |
Z2205000 |
Z2205100 |
|
电器容量 |
Electrical connection |
|
|
|
总电机功率 |
Total connected value |
4.5 kW 400 V ~50 Hz
or 230 V~50 Hz |
4.5 kW 400 V ~50 Hz
or 230 V~50 Hz |
|
卧铣电机功率 |
Motor horizontal spindle |
1.5 kW |
1.5 kW |
|
立铣电机功率 |
Motor vertical spindle |
1.1 / 2.2 kW |
1.1 / 2.2 kW |
|
冷却泵功率 |
Motor coolant pump |
40 W |
40 W |
|
进给电机功率 |
Motor table |
370 W |
370 W |
|
立铣 |
Spindle seat vertical |
|
|
|
主轴锥度 |
Spindle seat |
SK 40 |
SK 40 |
|
主轴行程 |
Spindle stroke |
120 mm |
120 mm |
|
钻孔能力 |
Drilling capacity in steel (S235JR) |
Ø 50 mm |
Ø 50 mm |
|
持续钻孔能力 |
Continuous drilling cap. steel (S235JR) |
Ø 40 mm |
Ø 40 mm |
|
套筒直径 |
Throat |
Ø 90 mm |
Ø 90 mm |
|
主轴转速 |
Spindle speed |
115-1750 rpm |
100-600/350-2000 rpm |
|
齿轮级数 |
Gear stages |
8 steps |
2 steps |
|
卧铣 |
Spindle seat horizontal |
|
|
|
主轴锥度 |
Spindle seat |
SK 40 |
SK 40 |
|
钻孔能力 |
Drilling capacity in steel (S235JR) |
Ø 50 mm |
Ø 50 mm |
|
持续钻孔能力 |
Continuous drilling cap. steel (S235JR) |
Ø 40 mm |
Ø 40 mm |
|
套筒直径 |
Throat |
Ø 90 mm |
Ø 90 mm |
|
主轴转速 |
Spindle speed |
60 - 1355 rpm |
60 - 1355 rpm |
|
齿轮级数 |
Gear stages |
9 steps |
9 steps |
|
十字工作台 |
Cross table |
|
|
|
工作台尺寸 |
Table length x Width |
1000x240mm
1200x240mm(For optional) |
1000x240mm
1200x240mm(For optional) |
|
T型槽尺寸 |
T-slot size/number |
14 mm |
14mm |
|
*大承载重量 |
Load capacity (max.) |
160 kg |
160 kg |
|
主轴端面至工作台面距离 |
Distance spindle - crosstable |
60-390 mm |
60-390 mm |
|
X轴自动行程 |
X-axis Travel automatic |
390 mm |
390 mm |
|
X轴工作台进给 |
X-axis Table feed |
24 - 720 mm/min |
24 - 720 mm/min |
|
Y轴手动行程 |
Y-axis Travel manual |
200 mm |
200 mm |
|
Z轴手动行程 |
Z-axis Travel manual |
340 mm |
340 mm |
|
尺寸 |
Dimensions |
|
|
|
长x宽x高 |
Length x Width x Height |
1400 x 1140 x 2200 mm |
1400 x 1140 x 2200 mm |
|
总重量 |
Total weight |
900 kg |
900 kg |
